16" Soft Close Drawer Slides

- 10 Pairs, 100 Lb Capacity, Full Extension

USD $109.99

Condition : New

Free Shipping

{{variant_type_name}} :
eBay
SKU: N/A This site contains affiliate links for which we may be compensated Home & Garden / Home Improvement / Building & Hardware / Cabinet Hardware / Drawer Slides

Notify me when the price drops

We will email you if we find a lower price on this product!

Target price (USD) $
10 Pairs of 16 Inch Hardware 3-Section Soft Close Full Extension Ball Bearing Side Mount Drawer Slides,100 LB Capacity Drawer Slide Description Item model number DR-16-10 Part Number DR-16-10 Batteries Required? No Finish Zinc Plated Number of Items 1 Mounting Type Side Mount Color Zinc Plated Material Alloy Steel Weight Limit 100 Pounds Item Weight 25.1 pounds Batteries Included? No Maximum Weight Capacity 100 Pounds Finish Type Zinc Plated Product Dimensions 16"L x 0.5"W x 1.77"Th Size 16 Inch

  • ★ 10 pairs of 16 inch,mounting screws included (extra screws offered for spare use). Attention: the mounting brackets are not included,please buy separately if need it.
  • ★ Side mounted Steel ball-bearing action.100 LB capacity.16'' in length.1.77'' in width.0.5'' in thickness.
  • ★ Zinc Plated and made of solid cold rolled steel.Rust resistant for your lifetime use.
  • ★ Soft-Close Design.Double springs design produces less noise at closing and opening,creating a silent life environment for your family.
  • ★ Guide for Choosing Size of Drawer Slides:To determine which size of slides are good for your drawer, please measure the length of the drawer without the frame board. And if the length is not even, please choose 1 inch shorter. The length of slides can't be longer than the cabinet case depth.And face frame cabinets will require a rear mounting bracket, whereas for faceless cabinets the slides are mounted directly on the side.

Product description Brand Value Product Specification

Width: 1.77''(45mm).

Thickness: 0.5''(12mm).

Material: cold rolled steel.

Finish Type: zinc plated.

Load capacity: 100LB

Screw Included?: Yes.

Mounting Type: side Mount

Easily pass the 48 hour salt spray test

Years of technological precipitation brings better life experience.

More Details Solid steel ball

Special ball fixing structure design, electrophoretic zinc treated beads and solid balls make the slides run more stably and smoothly.

Tail balance hole position

Add balance holes to balance the front, middle and rear stress of the outer rail, so as to avoid uneven stress of the rail caused by installation errors. Its bearing force is 1.6 times that of the ordinary soft close slides.

Black buckle

Press the black buckle to easily separate the slide rail for easy installation.

More Details Unique W shape Anti unhooking design

Eliminate the loss of buffer function caused by decoupling of buffer and inner rail after long use, prolonging the service life

Built in buffer

It is made of POM engineering plastics with high rigidity, high hardness and high wear resistance, which can resist repeated impact and wear.

The left and right double springs are evenly stressed, and the expansion is more stable.

Slide rail countersunk groove

Avoid the contact when installing the screw and the inner rail slides without resistance.

Forged steel forged contact

The contact and buffer forged by forged steel can withstand the cold of minus 20 degrees and the heat of 60 degrees.
